The BP6903A is a high voltage, high speed half-bridge pre-driver for power MOSFET and IGBT. Ithas inputs for both high side and low side, and twooutput channels with internal dead time to avoidcross-conduction. The input logic level is compatible with 3.3V/5V/15Vsignal. The floating high side channel can drive a N-channel power MOSFET or IGBT up to 600V.

Floating channel operation up to

600VRobust at negative transient voltage

Gate drive supply range from 10V to 20V

3.3V, 5V and 15V input logic compatible

Reverse input for low side

UVLO for both high side and low side

Built-in dead time

Available in SOP8 package
